Define the RTP part of the profile decompression context. More...
#include <c_rtp.h>
Data Fields | |
| struct ts_sc_comp | ts_sc |
| uint8_t | udp_checksum_trans_nr |
| uint8_t | rtp_version_trans_nr |
| uint8_t | rtp_padding_trans_nr |
| uint8_t | rtp_ext_trans_nr |
| uint8_t | rtp_pt_trans_nr |
| uint16_t | old_udp_check |
| uint16_t | old_rtp_version:2 |
| uint16_t | old_rtp_padding:1 |
| uint16_t | old_rtp_extension:1 |
| uint16_t | old_rtp_pt:7 |
| uint16_t | unused:5 |
| struct rtp_tmp_vars | tmp |
| RTP-specific temporary variables that are used during one single compression of packet. More... | |
Detailed Description
Define the RTP part of the profile decompression context.
This object must be used with the generic part of the decompression context rohc_comp_rfc3095_ctxt.
- See also
- rohc_comp_rfc3095_ctxt
Field Documentation
◆ old_rtp_extension
| uint16_t sc_rtp_context::old_rtp_extension |
The RTP Extension in previous RTP header
◆ old_rtp_padding
| uint16_t sc_rtp_context::old_rtp_padding |
The RTP Padding in previous RTP header
◆ old_rtp_pt
| uint16_t sc_rtp_context::old_rtp_pt |
The RTP Payload Type in previous RTP header
◆ old_rtp_version
| uint16_t sc_rtp_context::old_rtp_version |
The RTP Version in previous RTP header
◆ old_udp_check
| uint16_t sc_rtp_context::old_udp_check |
The UDP checksum in previous UDP header
◆ rtp_ext_trans_nr
| uint8_t sc_rtp_context::rtp_ext_trans_nr |
The nr of times the RTP eXtension (X) bit was added to compressed headers
◆ rtp_padding_trans_nr
| uint8_t sc_rtp_context::rtp_padding_trans_nr |
The nr of times the RTP Padding (P) bit was added to compressed headers
◆ rtp_pt_trans_nr
| uint8_t sc_rtp_context::rtp_pt_trans_nr |
The nr of times the RTP PT field was added to compressed headers
◆ rtp_version_trans_nr
| uint8_t sc_rtp_context::rtp_version_trans_nr |
The nr of times the RTP Version field was added to compressed headers
◆ tmp
| struct rtp_tmp_vars sc_rtp_context::tmp |
RTP-specific temporary variables that are used during one single compression of packet.
◆ ts_sc
| struct ts_sc_comp sc_rtp_context::ts_sc |
Structure to encode the TS field
◆ udp_checksum_trans_nr
| uint8_t sc_rtp_context::udp_checksum_trans_nr |
The number of times the checksum field was transmitted since last change
◆ unused
| uint16_t sc_rtp_context::unused |
The documentation for this struct was generated from the following file:
