The ROHC decompressor. More...
#include <rohc_decomp_internals.h>
Data Fields | |
| struct rohc_medium | medium |
| rohc_decomp_features_t | features |
| bool | enabled_profiles [ROHC_PROFILE_ID_MAJOR_MAX+1][ROHC_PROFILE_ID_MINOR_MAX+1] |
| rohc_mode_t | target_mode |
| struct rohc_decomp_ctxt ** | contexts |
| uint16_t | num_contexts_used |
| struct rohc_decomp_ctxt * | last_context |
| size_t | prtt |
| size_t | sn_feedback_min_bits |
| struct rohc_ack_rate_limits | ack_rate_limits |
| uint32_t | last_pkts_errors |
| struct rohc_ack_stats | last_pkt_feedbacks [ROHC_FEEDBACK_RESERVED] |
| uint8_t * | rru |
| size_t | rru_len |
| size_t | mrru |
| struct d_statistics | stats |
| rohc_trace_callback2_t | trace_callback |
| void * | trace_callback_priv |
Detailed Description
The ROHC decompressor.
Field Documentation
◆ ack_rate_limits
| struct rohc_ack_rate_limits rohc_decomp::ack_rate_limits |
The configuration for feedback rate-limiting
◆ contexts
| struct rohc_decomp_ctxt** rohc_decomp::contexts |
The array of decompression contexts that use the decompressor
◆ enabled_profiles
| bool rohc_decomp::enabled_profiles[ROHC_PROFILE_ID_MAJOR_MAX+1][ROHC_PROFILE_ID_MINOR_MAX+1] |
Which profiles are enabled and with one are not?
◆ features
| rohc_decomp_features_t rohc_decomp::features |
Enabled/disabled features for the decompressor
◆ last_context
| struct rohc_decomp_ctxt* rohc_decomp::last_context |
The last decompression context used by the decompressor
◆ last_pkt_feedbacks
| struct rohc_ack_stats rohc_decomp::last_pkt_feedbacks[ROHC_FEEDBACK_RESERVED] |
The information for feedback rate-limiting
◆ last_pkts_errors
| uint32_t rohc_decomp::last_pkts_errors |
Whether the last decompressed packets failed or not
◆ medium
| struct rohc_medium rohc_decomp::medium |
The medium associated with the decompressor
◆ mrru
| size_t rohc_decomp::mrru |
The Maximum Reconstructed Reception Unit (MRRU)
◆ num_contexts_used
| uint16_t rohc_decomp::num_contexts_used |
The number of decompression contexts in use
◆ prtt
| size_t rohc_decomp::prtt |
The maximum number of packets sent during one RTT
◆ rru
| uint8_t* rohc_decomp::rru |
The Reconstructed Reception Unit
◆ rru_len
| size_t rohc_decomp::rru_len |
The length (in bytes) of the Reconstructed Reception Unit
◆ sn_feedback_min_bits
| size_t rohc_decomp::sn_feedback_min_bits |
The minimum number of SN bits to transmit in feedbacks
◆ stats
| struct d_statistics rohc_decomp::stats |
Some statistics about the decompression processes
◆ target_mode
| rohc_mode_t rohc_decomp::target_mode |
The operation mode that the contexts shall target
◆ trace_callback
| rohc_trace_callback2_t rohc_decomp::trace_callback |
The callback function used to manage traces
◆ trace_callback_priv
| void* rohc_decomp::trace_callback_priv |
The private context of the callback function used to manage traces
The documentation for this struct was generated from the following file:
