Define the RTP part of the profile decompression context. More...
#include <c_rtp.h>
Data Fields | |
| size_t | udp_checksum_change_count |
| The number of times the UDP checksum field was added to the compressed header. More... | |
| struct udphdr | old_udp |
| The previous UDP header. More... | |
| size_t | rtp_version_change_count |
| The number of times the RTP Version field was added to the compressed header. More... | |
| size_t | rtp_pt_change_count |
| The number of times the RTP Payload Type (PT) field was added to the compressed header. More... | |
| size_t | rtp_padding_change_count |
| The number of times the RTP Padding (P) bit was added to the compressed header. More... | |
| size_t | rtp_extension_change_count |
| The number of times the RTP eXtension (X) bit was added to the compressed header. More... | |
| struct rtphdr | old_rtp |
| The previous RTP header. More... | |
| struct rtp_tmp_vars | tmp |
| RTP-specific temporary variables that are used during one single compression of packet. More... | |
| int | tss |
| Scaled RTP Time Stamp. More... | |
| int | tis |
| Whether the Time Stride field is present or not. More... | |
| struct ts_sc_comp | ts_sc |
| Structure to encode the TS field. More... | |
Detailed Description
Define the RTP part of the profile decompression context.
This object must be used with the generic part of the decompression context rohc_comp_rfc3095_ctxt.
- Warning
- The 2 first fields MUST stay at the beginning of the structure to be compatible with sc_udp_context
- See also
- rohc_comp_rfc3095_ctxt
Field Documentation
◆ old_rtp
| struct rtphdr sc_rtp_context::old_rtp |
The previous RTP header.
◆ old_udp
| struct udphdr sc_rtp_context::old_udp |
The previous UDP header.
◆ rtp_extension_change_count
| size_t sc_rtp_context::rtp_extension_change_count |
The number of times the RTP eXtension (X) bit was added to the compressed header.
◆ rtp_padding_change_count
| size_t sc_rtp_context::rtp_padding_change_count |
The number of times the RTP Padding (P) bit was added to the compressed header.
◆ rtp_pt_change_count
| size_t sc_rtp_context::rtp_pt_change_count |
The number of times the RTP Payload Type (PT) field was added to the compressed header.
◆ rtp_version_change_count
| size_t sc_rtp_context::rtp_version_change_count |
The number of times the RTP Version field was added to the compressed header.
◆ tis
| int sc_rtp_context::tis |
Whether the Time Stride field is present or not.
◆ tmp
| struct rtp_tmp_vars sc_rtp_context::tmp |
RTP-specific temporary variables that are used during one single compression of packet.
◆ ts_sc
| struct ts_sc_comp sc_rtp_context::ts_sc |
Structure to encode the TS field.
◆ tss
| int sc_rtp_context::tss |
Scaled RTP Time Stamp.
◆ udp_checksum_change_count
| size_t sc_rtp_context::udp_checksum_change_count |
The number of times the UDP checksum field was added to the compressed header.
The documentation for this struct was generated from the following file:
