#include <d_tcp_defines.h>
Data Fields | |
| uint8_t | version:4 |
| uint8_t | dscp_bits:6 |
| size_t | dscp_bits_nr |
| uint8_t | ecn_flags_bits:2 |
| size_t | ecn_flags_bits_nr |
| uint8_t | id_behavior:2 |
| size_t | id_behavior_nr |
| struct rohc_lsb_field16 | id |
| uint8_t | df:1 |
| size_t | df_nr |
| struct rohc_lsb_field8 | ttl_hl |
| uint8_t | proto |
| size_t | proto_nr |
| uint32_t | flowid:20 |
| size_t | flowid_nr |
| uint8_t | saddr [16] |
| size_t | saddr_nr |
| uint8_t | daddr [16] |
| size_t | daddr_nr |
| ip_option_context_t | opts [ROHC_TCP_MAX_IP_EXT_HDRS] |
| size_t | opts_nr |
| size_t | opts_len |
Detailed Description
The outer or inner IP bits extracted from ROHC headers
Field Documentation
◆ daddr
| uint8_t rohc_tcp_extr_ip_bits::daddr[16] |
The destination address bits found in static chain of IR header
◆ daddr_nr
| size_t rohc_tcp_extr_ip_bits::daddr_nr |
The number of source address bits
◆ df
| uint8_t rohc_tcp_extr_ip_bits::df |
The DF bits found in dynamic chain of IR/IR-DYN header or in extension header
◆ df_nr
| size_t rohc_tcp_extr_ip_bits::df_nr |
The number of DF bits found
◆ dscp_bits
| uint8_t rohc_tcp_extr_ip_bits::dscp_bits |
The IP DSCP bits
◆ dscp_bits_nr
| size_t rohc_tcp_extr_ip_bits::dscp_bits_nr |
The number of IP DSCP bits
◆ ecn_flags_bits
| uint8_t rohc_tcp_extr_ip_bits::ecn_flags_bits |
The IP ECN flag bits
◆ ecn_flags_bits_nr
| size_t rohc_tcp_extr_ip_bits::ecn_flags_bits_nr |
The number of IP ECN flag bits
◆ flowid
| uint32_t rohc_tcp_extr_ip_bits::flowid |
The IPv6 flow ID bits found in static chain of IR header
◆ flowid_nr
| size_t rohc_tcp_extr_ip_bits::flowid_nr |
The number of flow label bits
◆ id
| struct rohc_lsb_field16 rohc_tcp_extr_ip_bits::id |
The IP-ID bits
◆ id_behavior
| uint8_t rohc_tcp_extr_ip_bits::id_behavior |
The IP-ID behavior bits
◆ id_behavior_nr
| size_t rohc_tcp_extr_ip_bits::id_behavior_nr |
The number of IP-ID behavior bits
◆ opts
| ip_option_context_t rohc_tcp_extr_ip_bits::opts[ROHC_TCP_MAX_IP_EXT_HDRS] |
The parsed IP extension headers
◆ opts_len
| size_t rohc_tcp_extr_ip_bits::opts_len |
The length of the parsed IP extension headers
◆ opts_nr
| size_t rohc_tcp_extr_ip_bits::opts_nr |
The number of parsed IP extension headers
◆ proto
| uint8_t rohc_tcp_extr_ip_bits::proto |
The protocol/next header bits found static chain of IR header or in extension header
◆ proto_nr
| size_t rohc_tcp_extr_ip_bits::proto_nr |
The number of protocol/next header bits
◆ saddr
| uint8_t rohc_tcp_extr_ip_bits::saddr[16] |
The source address bits found in static chain of IR header
◆ saddr_nr
| size_t rohc_tcp_extr_ip_bits::saddr_nr |
The number of source address bits
◆ ttl_hl
| struct rohc_lsb_field8 rohc_tcp_extr_ip_bits::ttl_hl |
The IP TTL/HL bits
◆ version
| uint8_t rohc_tcp_extr_ip_bits::version |
The version bits found in static chain of IR header
The documentation for this struct was generated from the following file:
