The ROHC decompressor. More...
#include <rohc_decomp_internals.h>
Data Fields | |
| struct rohc_comp * | compressor |
| bool | do_auto_feedback_delivery |
| struct rohc_medium | medium |
| rohc_decomp_features_t | features |
| bool | enabled_profiles [D_NUM_PROFILES] |
| struct rohc_decomp_ctxt ** | contexts |
| size_t | num_contexts_used |
| struct rohc_decomp_ctxt * | last_context |
| unsigned int | maxval |
| The feedback interval limits. | |
| unsigned int | errval |
| unsigned int | okval |
| int | curval |
| unsigned char | rru [ROHC_MAX_MRRU] |
| size_t | rru_len |
| size_t | mrru |
| unsigned char | crc_table_3 [256] |
| unsigned char | crc_table_7 [256] |
| unsigned char | crc_table_8 [256] |
| struct d_statistics | stats |
| rohc_trace_callback_t | trace_callback |
| rohc_trace_callback2_t | trace_callback2 |
| void * | trace_callback_priv |
Detailed Description
The ROHC decompressor.
Field Documentation
| struct rohc_comp* rohc_decomp::compressor |
The compressor associated with the decompressor
| struct rohc_decomp_ctxt** rohc_decomp::contexts |
The array of decompression contexts that use the decompressor
| unsigned char rohc_decomp::crc_table_3[256] |
The table to enable fast CRC-3 computation
| unsigned char rohc_decomp::crc_table_7[256] |
The table to enable fast CRC-7 computation
| unsigned char rohc_decomp::crc_table_8[256] |
The table to enable fast CRC-8 computation
Variable related to the feedback interval
Whether to handle feedback delivery internally for compatibility with pre-1.7.0 versions
Which profiles are enabled and with one are not?
| unsigned int rohc_decomp::errval |
Variable related to the feedback interval
Enabled/disabled features for the decompressor
The last decompression context used by the decompressor
| unsigned int rohc_decomp::maxval |
The feedback interval limits.
maxval can be updated by the user thanks to the user_interactions function.
- See also:
- user_interactions
| struct rohc_medium rohc_decomp::medium |
The medium associated with the decompressor
| size_t rohc_decomp::mrru |
The Maximum Reconstructed Reception Unit (MRRU)
The number of decompression contexts in use
| unsigned int rohc_decomp::okval |
Variable related to the feedback interval
| unsigned char rohc_decomp::rru[ROHC_MAX_MRRU] |
The Reconstructed Reception Unit
| size_t rohc_decomp::rru_len |
The length (in bytes) of the Reconstructed Reception Unit
| struct d_statistics rohc_decomp::stats |
Some statistics about the decompression processes
The old callback function used to manage traces
The new callback function used to manage traces
The private context of the callback function used to manage traces
The documentation for this struct was generated from the following file:
