The ROHC compressor. More...
#include <rohc_comp_internals.h>
Data Fields | |
| int | enabled |
| Whether the compressor is enabled or not. | |
| struct medium | medium |
| struct c_context * | contexts |
| int | num_contexts |
| int | num_contexts_used |
| int | profiles [C_NUM_PROFILES] |
| Which profiles are enabled and with one are not? | |
| unsigned char | crc_table_2 [256] |
| unsigned char | crc_table_3 [256] |
| unsigned char | crc_table_6 [256] |
| unsigned char | crc_table_7 [256] |
| unsigned char | crc_table_8 [256] |
| struct rohc_feedback | feedbacks [FEEDBACK_RING_SIZE] |
| size_t | feedbacks_first |
| size_t | feedbacks_first_unlocked |
| size_t | feedbacks_next |
| The index of the next empty location in the feedback ring. | |
| int | num_packets |
| int | total_uncompressed_size |
| int | total_compressed_size |
| struct c_context * | last_context |
| rohc_comp_random_cb_t | random_cb |
| void * | random_cb_ctxt |
| size_t | wlsb_window_width |
| size_t | periodic_refreshes_ir_timeout |
| size_t | periodic_refreshes_fo_timeout |
| int | mrru |
| int | max_header_size |
| int | connection_type |
Detailed Description
The ROHC compressor.
Field Documentation
The connection type (currently not used)
| struct c_context* rohc_comp::contexts |
The array of compression contexts that use the compressor
Referenced by rohc_c_context().
| unsigned char rohc_comp::crc_table_2[256] |
The table to enable fast CRC-2 computation
Referenced by rohc_alloc_compressor().
| unsigned char rohc_comp::crc_table_3[256] |
The table to enable fast CRC-3 computation
Referenced by code_UO0_packet(), code_UO1_packet(), and rohc_alloc_compressor().
| unsigned char rohc_comp::crc_table_6[256] |
The table to enable fast CRC-6 computation
Referenced by code_UO2_packet(), and rohc_alloc_compressor().
| unsigned char rohc_comp::crc_table_7[256] |
The table to enable fast CRC-7 computation
Referenced by code_UO2_packet(), and rohc_alloc_compressor().
| unsigned char rohc_comp::crc_table_8[256] |
The table to enable fast CRC-8 computation
Referenced by c_generic_feedback(), code_IR_DYN_packet(), code_IR_packet(), and rohc_alloc_compressor().
Whether the compressor is enabled or not.
The compressor is enabled by default and may be disabled by user.
Referenced by rohc_alloc_compressor(), rohc_c_is_enabled(), rohc_c_set_enable(), and rohc_c_statistics().
The ring of outgoing feedbacks
Referenced by c_piggyback_feedback(), and rohc_alloc_compressor().
| size_t rohc_comp::feedbacks_first |
The index of the oldest feedback in the feedback ring
Referenced by c_piggyback_feedback(), and rohc_alloc_compressor().
The index of the oldest unlocked feedback in the feedback ring
Referenced by rohc_alloc_compressor().
| size_t rohc_comp::feedbacks_next |
The index of the next empty location in the feedback ring.
Referenced by c_piggyback_feedback(), and rohc_alloc_compressor().
| struct c_context* rohc_comp::last_context |
The last context used by the compressor
Referenced by rohc_alloc_compressor(), rohc_comp_get_last_packet_info(), and rohc_compress().
Maximum header size that will be compressed (currently not used)
Referenced by rohc_c_set_header().
| struct medium rohc_comp::medium |
The medium associated with the decompressor
Referenced by c_deliver_feedback(), code_IR_DYN_packet(), code_IR_packet(), code_UO0_packet(), code_UO1_packet(), code_UO2_packet(), rohc_alloc_compressor(), rohc_c_set_large_cid(), rohc_c_set_max_cid(), rohc_c_statistics(), and rohc_c_using_small_cid().
| int rohc_comp::mrru |
Maximum Reconstructed Reception Unit (currently not used)
Referenced by rohc_alloc_compressor(), rohc_c_set_mrru(), and rohc_c_statistics().
The number of compression contexts stored in the array
Referenced by rohc_c_context().
The number of compression contexts in use in the array
Referenced by rohc_c_statistics(), and rohc_compress().
The number of sent packets
Referenced by rohc_alloc_compressor(), rohc_c_statistics(), rohc_comp_set_periodic_refreshes(), rohc_comp_set_wlsb_window_width(), and rohc_compress().
The maximal number of packets sent in > FO states (= SO state) before changing back the state to FO (periodic refreshes)
Referenced by periodic_down_transition(), and rohc_comp_set_periodic_refreshes().
The maximal number of packets sent in > IR states (= FO and SO states) before changing back the state to IR (periodic refreshes)
Referenced by periodic_down_transition(), and rohc_comp_set_periodic_refreshes().
Which profiles are enabled and with one are not?
A value of 1 means that profile is enabled, 0 means disabled.
Referenced by rohc_activate_profile(), rohc_alloc_compressor(), and rohc_c_statistics().
The user-defined callback for random numbers
Referenced by c_udp_create(), c_udp_lite_create(), rohc_alloc_compressor(), and rohc_comp_set_random_cb().
Private data that will be given to the callback for random numbers
Referenced by c_udp_create(), c_udp_lite_create(), rohc_alloc_compressor(), and rohc_comp_set_random_cb().
The size of all the sent compressed ROHC packets
Referenced by rohc_alloc_compressor(), rohc_c_statistics(), and rohc_compress().
The size of all the received uncompressed IP packets
Referenced by rohc_alloc_compressor(), rohc_c_statistics(), and rohc_compress().
| size_t rohc_comp::wlsb_window_width |
The width of the W-LSB sliding window
Referenced by c_generic_create(), c_generic_encode(), c_rtp_create(), and rohc_comp_set_wlsb_window_width().
The documentation for this struct was generated from the following file:
