ROHC compression/decompression library
|
ROHC decompression context for the IP-only profile. More...
Go to the source code of this file.
Functions | |
unsigned int | ip_detect_ir_size (struct d_context *context, unsigned char *packet, unsigned int plen, unsigned int large_cid_len) |
Find the length of the IR header. | |
unsigned int | ip_detect_ir_dyn_size (struct d_context *context, unsigned char *packet, unsigned int plen, unsigned int large_cid_len) |
Find the length of the IR-DYN header. | |
int | ip_decode_dynamic_ip (struct d_generic_context *context, const unsigned char *packet, unsigned int length, unsigned char *dest) |
Decode the IP dynamic part of the ROHC packet. | |
int | ip_get_static_part (void) |
Get the size of the static part of an IR packet (without IP) |
ROHC decompression context for the IP-only profile.
int ip_decode_dynamic_ip | ( | struct d_generic_context * | context, |
const unsigned char * | packet, | ||
unsigned int | length, | ||
unsigned char * | dest | ||
) |
Decode the IP dynamic part of the ROHC packet.
context | The generic decompression context |
packet | The ROHC packet to decode |
length | The length of the ROHC packet |
dest | Not used |
References d_generic_context::active1, d_generic_context::active2, d_ip_id_init(), d_lsb_init(), GET_NEXT_16_BITS, d_generic_changes::ip, ip_get_version(), d_generic_context::ip_id1, d_generic_context::ip_id2, IPV4, ipv4_get_id(), d_generic_context::multiple_ip, PACKET_IR, PACKET_IR_DYN, d_generic_context::packet_type, rohc_debugf, sn, and d_generic_context::sn.
Referenced by d_ip_create(), udp_decode_dynamic_udp(), and udp_lite_decode_dynamic_udp().
unsigned int ip_detect_ir_dyn_size | ( | struct d_context * | context, |
unsigned char * | packet, | ||
unsigned int | plen, | ||
unsigned int | large_cid_len | ||
) |
Find the length of the IR-DYN header.
This function is one of the functions that must exist in one profile for the framework to work.
Basic structure of the IR-DYN packet (5.7.7.2): 0 1 2 3 4 5 6 7 --- --- --- --- --- --- --- --- 1 : Add-CID octet : if for small CIDs and CID != 0 +---+---+---+---+---+---+---+---+ 2 | 1 1 1 1 1 0 0 0 | IR-DYN packet type +---+---+---+---+---+---+---+---+ : : 3 / 0-2 octets of CID info / 1-2 octets if for large CIDs : : +---+---+---+---+---+---+---+---+ 4 | Profile | 1 octet +---+---+---+---+---+---+---+---+ 5 | CRC | 1 octet +---+---+---+---+---+---+---+---+ | | 6 / Dynamic chain / variable length | | +---+---+---+---+---+---+---+---+ 7 | SN | 2 octets if not RTP +---+---+---+---+---+---+---+---+ : : 8 / Payload / variable length : : - - - - - - - - - - - - - - - -
The function computes the length of the fields 2 + 4-7, ie. the first byte, the Profile and CRC fields, the dynamic chains (outer and inner IP headers) and the SN.
context | The decompression context |
packet | The IR-DYN packet after the Add-CID byte if present (ie. the field 2 in the figure) |
plen | The length of the IR-DYN packet minus the Add-CID byte |
large_cid_len | The size of the large CID field (ie. field 3 in the figure) |
References d_generic_detect_ir_dyn_size().
Referenced by udp_detect_ir_dyn_size().
unsigned int ip_detect_ir_size | ( | struct d_context * | context, |
unsigned char * | packet, | ||
unsigned int | plen, | ||
unsigned int | large_cid_len | ||
) |
Find the length of the IR header.
This function is one of the functions that must exist in one profile for the framework to work.
Basic structure of the IR packet (5.7.7.1): 0 1 2 3 4 5 6 7 --- --- --- --- --- --- --- --- 1 | Add-CID octet | if for small CIDs and CID != 0 +---+---+---+---+---+---+---+---+ 2 | 1 1 1 1 1 1 0 | D | +---+---+---+---+---+---+---+---+ | | 3 / 0-2 octets of CID info / 1-2 octets if for large CIDs | | +---+---+---+---+---+---+---+---+ 4 | Profile | 1 octet +---+---+---+---+---+---+---+---+ 5 | CRC | 1 octet +---+---+---+---+---+---+---+---+ | | 6 | Static chain | variable length | | +---+---+---+---+---+---+---+---+ | | 7 | Dynamic chain | present if D = 1, variable length | | +---+---+---+---+---+---+---+---+ 8 | SN | 2 octets if not RTP +---+---+---+---+---+---+---+---+ | | 9 | Payload | variable length | | - - - - - - - - - - - - - - - -
The function computes the length of the fields 2 + 4-8, ie. the first byte, the Profile and CRC fields, the static and dynamic chains (outer and inner IP headers) and the SN.
context | The decompression context |
packet | The pointer on the IR packet minus the Add-CID byte (ie. the field 2 in the figure) |
plen | The length of the IR packet minus the Add-CID byte |
large_cid_len | The size of the large CID field (ie. field 3 in the figure) |
References d_generic_detect_ir_size().
Referenced by udp_detect_ir_size().
int ip_get_static_part | ( | void | ) |
Get the size of the static part of an IR packet (without IP)
